Banza Aluminium is a leading aluminium manufacturer and supplier based in Kinshasa, Congo, renowned for delivering high-quality aluminium solutions tailored to diverse industrial needs. Specializing in Aluminium 1050 forgings, the company offers exceptional products known for their superior strength, corrosion resistance, and versatility. With a commitment to precision engineering and customer satisfaction, Banza Aluminium supports a wide range of sectors, including aerospace, automotive, and construction. Their expertise and innovative approaches ensure reliable, cost-effective solutions for modern manufacturing challenges.
Aluminium 1050 is a commercially pure aluminium grade containing 99.5% aluminium, with trace elements of iron (0.4% max) and silicon (0.25% max). This high purity gives it excellent corrosion resistance and thermal conductivity. Aluminium 1050 forgings exhibit moderate strength with a tensile strength of 65-95 MPa and a yield strength of 30-45 MPa, depending on the temper. Its elongation at break can reach up to 40%, offering good ductility. The material’s excellent workability makes it ideal for applications requiring formability and high conductivity.
Standards : ASTM B247, B247
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S |
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
Banza Aluminium based in Kinshasa, Congo is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 1050 Forgings to meet specific project needs. Our team at Banza Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@banzaaluminium.com
Aluminium 1050 forgings are widely used in industries requiring high purity and excellent corrosion resistance. Its applications include the manufacture of heat exchangers, electrical conductors, and transformers, where high electrical and thermal conductivity is essential. It is also used in the food and chemical processing industries for equipment such as tanks, pipes, and fittings due to its resistance to corrosion. Additionally, Aluminium 1050 is utilized in architectural applications like cladding and signage, as well as in automotive and aerospace components requiring lightweight and durable materials.
